1. Importance of Proper Cable Selection
Incorrect cable sizing causes:
- Voltage drop
- Heat buildup
- Energy loss
- Reduced system efficiency
Ni-Cd batteries used in high-current storage systems require low-resistance interconnections.
2. Cable Sizing Principles
2.1 Current Rating Calculation
Cable cross-section should be determined based on:
- Maximum discharge current
- Ambient temperature
- Cable length
Recommended copper cable sizes:
- Small systems: 25–50 mm²
- Medium systems: 70–120 mm²
- Large storage banks: ≥150 mm²
3. Busbar Design Guidelines
3.1 Advantages of Copper Busbars
- Lower resistance than cables
- Improved current distribution
- Higher mechanical strength
3.2 Installation Tips
- Use tin-plated copper busbars
- Ensure smooth contact surfaces
- Apply anti-oxidation grease
- Tighten bolts with torque wrench
4. Minimizing Voltage Drop
To reduce voltage drop:
- Keep interconnect lengths short
- Use symmetrical wiring layouts
- Avoid unnecessary joints
5. Conclusion
Proper cable and busbar design ensures:
- Efficient energy transfer
- Stable system performance
- Reduced overheating risks
